Separating new conrod

On new conrods it is possible that the breaking point is not fully separated. Proceed as follows if the conrod bearing cap cannot be removed by hand:

• To avoid damage, gently clamp conrod in a vice with protection jaws, as shown in illustration.

• Clamp conrod below dashed line.

• Unscrew bolts -arrows- around 5 turns.

• Using a plastic hammer, carefully knock against conrod bearing cap -arrow- until it is loose.
