Running gear, axles, steering · Wheels, tyres, vehicle geometry · Wheel alignment
Wheel alignment procedure
Always adhere to the following procedure!
- Observe the instructions for the wheel alignment unit.
Alignment procedure
Start → Carry out wheel runout com‐ → Bounce springs.
pensation.
↓
| Turn steering wheel to straight-ahead position and lock in place | 1) |
←
←
Turn steering wheel to Measure vehicle height. Fit brake pedal depressor - V.A.G
1869/2-
↓
| Check front axle camber |
→
Is actual value within toler‐
no
ance?
↓
↓
↓ ← ←
yes
Camber correction ⇒ 3.8 Adjusting camber at front wheels
6C 2014–2017 ↓
↓
↓ ← ←
←
←
←
↓
| Check rear axle camber |
→
→
Check rear axle camber Is actual value within toler‐
no
ance?
↓
↓
↓ ← ←
yes
6C 2014–2017 Checking ⇒ 3.9 Adjusting camber on rear axle
↓
↓
↓ ← ←
←
←
←
↓
| Check rear axle toe |
→
→
Check rear axle toe Is actual value within toler‐
6C 2014–2017 no
ance?
↓
↓
↓ ← ←
yes
6C 2014–2017 Checking ⇒ 3.10 Adjusting toe at rear axle
↓
↓
↓ ← ←
←
←
←
↓
| Check front axle caster |
→
→
Check front axle caster Is actual value within toler‐
6C 2014–2017 no
ance?
↓
↓
↓ ← ←
yes
6C 2014–2017 Inspect axle components and body
↓
↓
↓ ← ←
←
←
←
↓
| Check front axle toe |
→
→
Check front axle toe Is actual value within toler‐
6C 2014–2017 no
ance?
↓
↓
| End |
yes
6C 2014–2017 Adjusting ⇒ 3.11 Adjusting front axle toe
↑
↓
↑ ← ←
←
←
←
1) If steering wheel is not centred, it must be straightened after wheel alignment is finished. Then, perform basic setting of steering angle sender - G85- using vehicle diagnostic tester ⇒ Vehicle diagnostic tester.
